A modern bathroom works as a connected system. Your basin needs a suitable waste connection and bottle trap. A health faucet or jet spray needs the right water connection and hose. Floor drainage has to match the floor layout, while bathroom accessories need to be positioned where they are useful without interfering with doors, movement or other fixtures.

Sanjay Chilly brings these requirements together across its range of bathroom accessories, plumbing components and drainage solutions. The goal of this checklist is not to tell you to buy every fixture, but to help you identify what your bathroom actually needs before installation begins.

Quick Bathroom Plumbing Fixtures Checklist

1. Start With the Bathroom Layout

Before choosing individual bathroom plumbing fixtures, understand how the bathroom will be used. Mark the locations of the basin, toilet, shower, floor drains and storage areas.

Then consider how people will move through the space. A towel holder positioned too close to a shower door, a soap dispenser behind the basin or a health faucet installed outside comfortable reach can make an otherwise well-designed bathroom inconvenient.

2. Measure Before You Buy

One of the most common bathroom installation mistakes is buying first and measuring later. Plumbing fixtures may look standard, but the available installation space and existing connections can vary.

• Measure the available wall width for mounted accessories.
• Check the height and position of existing water outlets.
• Measure basin and sink outlet dimensions.
• Check the diameter and position of drainage outlets.
• Measure the distance between fixtures where hoses or connectors are required.
• Check door, drawer and cabinet clearances around the fixture.
• For replacement products, measure the existing component before removing it.

For plumbing components, dimensions are particularly important. A visually compatible product is not necessarily a technically compatible one.

3. Check the Water-Supply Connections

Water-supply connections are easy to overlook because most of the plumbing eventually sits behind or beneath the visible bathroom fixtures. However, the connection is one of the most important parts of the installation.

A suitable connection hose provides a flexible link between compatible water-supply points and fixtures. Sanjay Chilly currently offers stainless steel, PVC and PTMT connection hose options for applications including wash basins, health faucets, water heaters and other sanitary fixtures.

Before buying a connection hose, check:

• Required hose length
• Connection or thread type
• Fixture compatibility
• Available installation space
• Material and construction
• Whether the hose can be routed without sharp bends

4. Check Basin Waste Components Together

A wash basin is more than the visible faucet and ceramic bowl. The components underneath it determine how wastewater leaves the basin and how the connection integrates with the drainage line.

Start with the waste coupling. Sanjay Chilly's range includes different styles and constructions, including brass and stainless steel options. Check the outlet arrangement, thread type and basin compatibility before installation.

Next, consider the bottle trap. Installed beneath a basin or sink, a bottle trap helps direct wastewater towards the drainage system while retaining water in the trap to help prevent sewer gases from entering the bathroom.

Basin Plumbing Checklist

• Confirm basin outlet size.
• Select a compatible waste coupling.
• Check bottle trap dimensions and connection type.
• Confirm the trap outlet matches the drainage connection.
• Leave sufficient access for cleaning and maintenance.
• Check that the finished installation does not interfere with drawers or storage below the basin.

5. Choose the Right Toilet Hygiene Fixture

Health faucets and jet sprays are common bathroom hygiene fixtures, but the terminology can overlap. What matters during installation is the actual product configuration, water connection, mounting position, hose and operating mechanism.

Sanjay Chilly's Health Faucet collection includes multiple designs with options such as brass fittings and 1-metre hoses, depending on the model. The range includes stainless steel and plastic options.

You can also explore the Jet Spray collection when planning toilet-area fittings.

Before installation, check:

• Where the water supply will connect.
• Whether the hose reaches comfortably from the connection point.
• Where the wall holder will be positioned.
• Whether the spray can be operated without interfering with nearby fixtures.
• Whether the connection is accessible for maintenance.

6. Think About the Hose Length and Routing

Hose length is a small detail that can have a surprisingly large impact on everyday usability. A hose that is too short may restrict movement, while an unnecessarily long hose can look untidy and create unwanted loops around the fixture.

This applies to health faucets, jet sprays and other flexible plumbing connections. Before installation, measure the distance between the water outlet and the intended position of the fixture.

7. Check the Material and Finish

Bathroom fixtures operate in a moisture-rich environment, so material selection matters. The right material depends on where the product will be installed, how frequently it will be used and how it will be cleaned.

Sanjay Chilly's bathroom accessories collection includes multiple contemporary ranges such as Nexa, Aristo, Stello, Velora and Imperial finishes. The current collection includes towel holders, towel racks, robe hooks, soap dishes, dispensers, toothbrush holders, toilet paper holders and other organisation products.

Explore the complete Bathroom Accessories collection when planning the finishing details of your bathroom.

8. Plan Accessories Before Tiling

Bathroom accessories may appear to be finishing touches, but their positions should be decided before the bathroom is completely finished.

Think about where towels, soap, toilet paper and everyday items will actually be used. A towel rack should be accessible without standing inside the wet zone. A soap dispenser should be within comfortable reach of the basin. A robe hook should not obstruct the door or shower enclosure.

9. Match the Drainage With the Floor Layout

Bathroom drainage should be planned before the floor is tiled. The type of drainage product you choose depends on the floor layout, outlet position, slope, water flow and desired finish.

For point drainage, explore Sanjay Chilly's Floor Drainer collection. These products are designed for suitable bathroom, shower, balcony and utility applications.

If your shower layout is designed around linear drainage, the Shower Drain Channel collection provides options intended for shower areas where channel drainage is appropriate.

The key is to select the drainage system before finalising the floor slope and outlet arrangement, rather than trying to make the chosen product fit after tiling.

10. Check the Floor Drain Dimensions and Access

A floor drain needs to work with the actual floor construction. Check the outlet position, drainage capacity, installation depth and finished floor level before installation.

Also consider maintenance. Removable strainers and accessible drainage components can make cleaning and routine inspection easier.

Sanjay Chilly's Floor Drainer range includes stainless steel options and different design series. Select the configuration that suits your floor and plumbing arrangement rather than choosing only by appearance.

11. Check the Drainage Accessories Around the Shower

The shower area usually receives the highest volume of water in a bathroom, so drainage planning becomes especially important here.

Before buying a shower drainage fixture, consider the location of the outlet, floor slope, expected water flow and final floor finish. If the bathroom uses tile or another decorative floor surface, the drain design should also complement the overall layout.

For bathrooms where pest and odour control are important considerations, explore the Cockroach Trap Drain collection as part of the drainage planning process.

12. Compare Function Before Finish

A premium-looking bathroom fixture can still be the wrong choice if it does not suit the installation. Before comparing finishes, make sure the basic technical requirements are satisfied.

13. Check What Needs to Be Installed Before Tiling

Timing matters just as much as product selection. Some bathroom components need to be positioned or connected before tiles, flooring or wall finishes are completed.

14. Keep Maintenance in Mind

A bathroom should not only look good on installation day. The plumbing fixtures should remain accessible enough for routine cleaning, inspection and servicing.

Keep access around bottle traps, waste connections and hoses wherever possible. Drain covers and strainers should be removable where the product design requires regular cleaning.

For wall-mounted accessories, avoid placing products where they make cleaning around the basin, toilet or shower unnecessarily difficult.

15. Build a Complete Bathroom Fixture List

Once the plumbing layout is confirmed, create a room-by-room purchasing list. This helps prevent the common situation where the major sanitaryware has been purchased but small components are missing during installation.

Common Mistakes to Avoid When Buying Bathroom Fixtures

Buying Without Measuring

Even a well-designed product can become difficult to install if the available space or connection does not match. Measure first.

Assuming Plumbing Connections Are Universal

Waste couplings, bottle traps and connection hoses can differ in dimensions and connection arrangements. Always check the specifications.

Choosing Only by Appearance

A finish should complement the bathroom, but function and compatibility should come first.

Forgetting the Floor Slope

Drainage products depend on how water moves across the finished floor. Confirm the drainage layout before tiling.

Installing Accessories Without Planning Reach

A towel holder, soap dispenser or health faucet should be positioned according to actual use rather than simply filling available wall space.

Closing Plumbing Without Testing

Test water supply, drainage and accessible connections before permanently closing walls, floors or cabinets.

Final Bathroom Plumbing Fixtures Checklist

• Measure the bathroom and identify each fixture location.
• Confirm basin, toilet and shower plumbing points.
• Check water-supply connection sizes and positions.
• Select suitable connection hoses and confirm their length.
• Match waste couplings with basin or sink outlets.
• Choose a compatible bottle trap for the basin installation.
• Plan the health faucet or jet spray position near the toilet.
• Choose floor or shower drainage according to the floor layout.
• Check floor slope and drainage outlet position before tiling.
• Plan towel holders, soap dispensers, hooks and other accessories.
• Consider material, finish and maintenance requirements.
• Keep serviceable plumbing components accessible.
• Test plumbing connections before closing inaccessible areas.
• Confirm product specifications with your installer before purchase.

FAQ

What should I check before buying bathroom plumbing fixtures?

Check dimensions, connection type, material, installation method, available space, water-supply requirements, drainage arrangement and maintenance access. Product compatibility should be confirmed before purchase.

Which plumbing components are needed for a wash basin?

A wash basin installation commonly requires a suitable waste coupling, bottle trap and compatible water-supply connection hoses, depending on the basin and faucet configuration.

How do I choose a connection hose for a bathroom fixture?

Check the required length, connection type, fixture compatibility, material and available installation space. The hose should reach the connection comfortably without excessive bending or stretching.

Should bathroom accessories be installed before or after tiling?

The exact timing depends on the product and installation method. However, positions for wall-mounted accessories should be planned before finishing the walls so mounting locations, clearances and plumbing requirements are properly considered.

What should I check before installing a floor drainer?

Check the floor outlet, finished floor level, drainage direction, available installation depth, floor slope and compatibility with the selected drainer. Planning the drainage before tiling is important.

Are health faucets and jet sprays the same?

The terminology can overlap because both can refer to handheld toilet sprays used for personal cleaning. When buying, compare the actual product construction, hose, fittings, mounting arrangement and specifications rather than relying only on the name.

Why is a bottle trap important under a wash basin?

A bottle trap directs wastewater from the basin into the drainage system while retaining water in the trap. This water seal helps prevent sewer gases and unpleasant odours from entering the bathroom.

How can I avoid plumbing problems after bathroom installation?

Measure before purchasing, verify connection compatibility, plan drainage and accessory positions before finishing, test accessible plumbing connections and keep serviceable components accessible for future maintenance.
